Expandable Modular House

Expandable modular houses offer unmatched flexibility and convenience. Their modular design allows for easy customization and expansion, providing a spacious, functional, and cost-effective living solution. Perfect for families or anyone needing a flexible living arrangement.
Send Inquiry
Download
Product Description





Expandable Modular House Introduction
product-1442-939

Welcome to the future of home design with our Expandable Modular House. This innovative living solution combines the strength and reliability of modular construction with the flexibility of expandable design, offering a perfect blend of comfort, efficiency, and sustainability. Whether you're looking for a cozy family home, a versatile workspace, or a unique commercial venture, our modular house is tailored to meet your every need.

With its sleek and modern aesthetics prominently featured throughout the page layout, it's easy to see why our expandable modular house is the ultimate choice for forward-thinking individuals and businesses.



EXPANDABLE CONTAINER
Expandable Size:6300*5900*2480mm Foldable Size:5900*2200*2480mm
Item Description Unit Qty
Main Frame top frame - middle galvanized formed beams,zinc=80g/m³，1900*150mm pc 2
galvanized square tube 80*100*2.5mm*6000mm pc 2
purlin: galvanized square tube 40*60*1.5mm*1900mm pc 5
purlin: galvanized square tube 20*40*1.0mm*6000mm pc 2
insulation:75mm glasswool set 1
0.5mm galvanized sheet +995 silicone glue set 1
interior ceiling:ceiling tile + angle iron set 1
galvanized hanging corner zinc=80g/m³,210*150*160mm pc 4
top frame - double sides galvanized square tube 80*100*1.5mm*6000mm pc 4
galvanized square tube 30*50mm*2000mm pc 4
thickened angle iron 6000mm pc 4
bottom frame - middle galvanized formed beams,zinc=80g/m³，1900*150mm pc 2
galvanized square tube 80*100*2.5mm*6000mm pc 2
galvanized square tube 80*100*2.5mm*1900mm pc 1
galvanized square tube 30*50*1900mm pc 1
purlin: galvanized square tube 40*60*1.5mm*2000mm pc 8
purlin: galvanized square tube 40*60*1.5mm*1600mm pc 2
squatting rack：40*40*6000mm pc 2
galvanized square tube：20*40*6000mm pc 2
fiber cement board 1175*1820mm pc 5
1.6mm rubber flooring +glue + bonding wire set 1
bottom frame - double sides galvanized square tube 40*60*1.5mm*6000mm pc 2
galvanized square tube 40*60*1.5mm*2200mm pc 22
galvanized square tube 60*60*1.4mm*6000mm pc 2
galvanized square tube 40*80*1.4mm*6000mm pc 2
galvanized square tube 40*40*6000mm pc 4
galvanized square tube 20*40*6000mm pc 6
cladding：2200mm pc 4
thickened angle iron 6000mm pc 12
bamboo plywood pc 9
1.6mm rubber flooring +glue + bonding wire set 2
frame - front & rear wall galvanized square tube 60*80*1.5mm*2220mm pc 4
galvanized square tube 40*60*1.5mm*2220mm pc 16
thickened angle iron 6000mm pc 12
middle partition galvanized square tube 60*80*1.5mm*2300mm pc 1
galvanized square tube 40*50*1.5mm*2200mm pc 2
galvanized square tube 40*50*1.5mm*2340mm pc 2
thickened angle iron 6000mm pc 3
column galvanized column,zinc=80g/m³，2160*210*150mm pc 4
reinforcement ribs pc 8
galvanized square tube 40*80*1.5mm*2200mm pc 4
galvanized square tube 40*60*1.5mm*2200mm pc 2
frame - side wall galvanized square tube 40*60*1.5mm*6000mm pc 4
galvanized square tube 40*60*1.5mm*2100mm pc 4
thickened angle iron 6000mm pc 6
Door entrance KFC door 1940*2170mm set 1
toilet aluminum door 840*1970mm set 1
room Fireproof lock door 930*1970mm set 2
Broken bridge window   aluminum sliding window pc 5
  aluminum frosted glasses window pc 1
Wall panel EPS 50mm fire retardant EPS， 14kg/m³， 0.4/0.4mm set 1
Electric system   Industrial plug - 1set，D/B - 1pc，2P leakage protector - 1pc，breaker 2P*1pc+1P*1pc，
30W-LED strip light - 2pcs，3 holes socket - 1pc，5 holes socket -3p,switch - 1pc，
Three-core sheathed wire：input-6mm²，A/C-4mm²，socket-2.5mm²，light-1.5mm²		 set 1
Sanitary ware   toilet*1 set，washing basin*1 set set 1
Pipes   outlet pipe φ110-PVC ，inlet pipe φ25-PPR ，pipe fittings set 1
Accessories   220mm aluminum plate，50 iron channel，cladding,screw,glue,hinge,sealing set 1



Key Features



Expandable Design: Our expandable modular house is designed to grow with your needs. Start small and expand as your family grows or your business evolves. The expandable feature is strategically mentioned multiple times on the page, highlighting its unparalleled versatility and adaptability.
Modular Construction: Each section of the house is built using standardized modules, ensuring easy assembly, disassembly, and transportation. This modular approach not only speeds up construction time but also allows for future modifications or additions, making it the perfect solution for those who value flexibility and efficiency.
Sustainable Materials: Crafted from eco-friendly materials, our modular house reduces waste and promotes sustainability. The use of recycled and renewable resources ensures a minimal carbon footprint, making it an ideal choice for environmentally conscious individuals and businesses.product-1080-951

FAQ



How easy is it to expand the modular house?


Expanding our modular house is a straightforward process. Our design team will work with you to determine the best expansion plan, and our professional installation services ensure seamless integration of additional modules. With minimal disruption to your daily routine, you can enjoy a larger living space in no time.

What customization options are available?


Customization options are virtually limitless with our expandable modular house. From interior layouts and finishes to exterior designs and features, you can tailor the house to reflect your personal style and functional requirements. Our design team will work closely with you to bring your vision to life, ensuring a truly unique and personalized living experience.

How durable is the modular construction?


Our modular house is built to last. Constructed using high-quality materials and advanced engineering techniques, it's designed to withstand extreme weather conditions and provide long-lasting durability. With a focus on strength and reliability, you can trust our modular house to provide a safe and secure living environment for years to come.product-804-967

Is the modular house energy-efficient?


Absolutely. Our modular house is designed with energy efficiency in mind. Advanced insulation materials, energy-efficient windows and doors, and sustainable energy systems contribute to lower energy consumption and reduced environmental impact. With a focus on sustainability, you can enjoy a comfortable living space while contributing to a greener future.

What is the timeline for construction and delivery?


Our modular construction process allows for a faster build timeline compared to traditional construction methods. From design to delivery, we work efficiently to ensure your modular house is ready for occupancy as soon as possible. Our team will provide regular updates and communicate transparently throughout the process, ensuring a seamless and stress-free experience.

Contact Us


Discover the future of home design with our Expandable Modular House. Whether you're looking for a cozy family home, a versatile workspace, or a unique commercial venture, our modular house offers a perfect blend of functionality, durability, and sustainability. Visit our product page for more details and start designing your dream space today!
