Expandable Container House

Expandable container houses offer unparalleled flexibility and space-saving. Their innovative design allows for easy expansion, transforming compact units into spacious, functional homes. Perfect for growing families, urban living, or temporary housing needs.
Send Inquiry
Download
Product Description





Expandable Container House Introduction


product-1441-1080



Introducing our revolutionary Expandable Container House, a cutting-edge living solution designed to maximize space and minimize environmental impact. This innovative structure combines the durability of shipping containers with the versatility of modular design, creating a comfortable, efficient, and sustainable living environment. Perfect for both residential and commercial use, our container house seamlessly adapts to your needs, offering unparalleled flexibility and convenience.



EXPANDABLE CONTAINER
Expandable Size:6300*5900*2480mm Foldable Size:5900*2200*2480mm
Item Description Unit Qty
Main Frame top frame - middle galvanized formed beams,zinc=80g/m³，1900*150mm pc 2
galvanized square tube 80*100*2.5mm*6000mm pc 2
purlin: galvanized square tube 40*60*1.5mm*1900mm pc 5
purlin: galvanized square tube 20*40*1.0mm*6000mm pc 2
insulation:75mm glasswool set 1
0.5mm galvanized sheet +995 silicone glue set 1
interior ceiling:ceiling tile + angle iron set 1
galvanized hanging corner zinc=80g/m³,210*150*160mm pc 4
top frame - double sides galvanized square tube 80*100*1.5mm*6000mm pc 4
galvanized square tube 30*50mm*2000mm pc 4
thickened angle iron 6000mm pc 4
bottom frame - middle galvanized formed beams,zinc=80g/m³，1900*150mm pc 2
galvanized square tube 80*100*2.5mm*6000mm pc 2
galvanized square tube 80*100*2.5mm*1900mm pc 1
galvanized square tube 30*50*1900mm pc 1
purlin: galvanized square tube 40*60*1.5mm*2000mm pc 8
purlin: galvanized square tube 40*60*1.5mm*1600mm pc 2
squatting rack：40*40*6000mm pc 2
galvanized square tube：20*40*6000mm pc 2
fiber cement board 1175*1820mm pc 5
1.6mm rubber flooring +glue + bonding wire set 1
bottom frame - double sides galvanized square tube 40*60*1.5mm*6000mm pc 2
galvanized square tube 40*60*1.5mm*2200mm pc 22
galvanized square tube 60*60*1.4mm*6000mm pc 2
galvanized square tube 40*80*1.4mm*6000mm pc 2
galvanized square tube 40*40*6000mm pc 4
galvanized square tube 20*40*6000mm pc 6
cladding：2200mm pc 4
thickened angle iron 6000mm pc 12
bamboo plywood pc 9
1.6mm rubber flooring +glue + bonding wire set 2
frame - front & rear wall galvanized square tube 60*80*1.5mm*2220mm pc 4
galvanized square tube 40*60*1.5mm*2220mm pc 16
thickened angle iron 6000mm pc 12
middle partition galvanized square tube 60*80*1.5mm*2300mm pc 1
galvanized square tube 40*50*1.5mm*2200mm pc 2
galvanized square tube 40*50*1.5mm*2340mm pc 2
thickened angle iron 6000mm pc 3
column galvanized column,zinc=80g/m³，2160*210*150mm pc 4
reinforcement ribs pc 8
galvanized square tube 40*80*1.5mm*2200mm pc 4
galvanized square tube 40*60*1.5mm*2200mm pc 2
frame - side wall galvanized square tube 40*60*1.5mm*6000mm pc 4
galvanized square tube 40*60*1.5mm*2100mm pc 4
thickened angle iron 6000mm pc 6
Door entrance KFC door 1940*2170mm set 1
toilet aluminum door 840*1970mm set 1
room Fireproof lock door 930*1970mm set 2
Broken bridge window   aluminum sliding window pc 5
  aluminum frosted glasses window pc 1
Wall panel EPS 50mm fire retardant EPS， 14kg/m³， 0.4/0.4mm set 1
Electric system   Industrial plug - 1set，D/B - 1pc，2P leakage protector - 1pc，breaker 2P*1pc+1P*1pc，
30W-LED strip light - 2pcs，3 holes socket - 1pc，5 holes socket -3p,switch - 1pc，
Three-core sheathed wire：input-6mm²，A/C-4mm²，socket-2.5mm²，light-1.5mm²		 set 1
Sanitary ware   toilet*1 set，washing basin*1 set set 1
Pipes   outlet pipe φ110-PVC ，inlet pipe φ25-PPR ，pipe fittings set 1
Accessories   220mm aluminum plate，50 iron channel，cladding,screw,glue,hinge,sealing set 1





Expandable Container House Key Features



Space-Efficient Design: Our expandable container house features a compact footprint that can be expanded to double or triple its original size, allowing you to utilize space more effectively. With this feature prominently displayed in the page layout, you can envision how it can transform your living or working area.
Modular Construction: Each section of the house is built using standardized modules, ensuring easy assembly, disassembly, and transportation. This modular approach not only speeds up construction time but also allows for future expansions or modifications to suit your evolving needs. The modular design is strategically mentioned throughout the page to emphasize its versatility.
Sustainable Materials: Crafted from recycled shipping containers, our expandable container house reduces waste and promotes sustainability. The use of eco-friendly materials and energy-efficient technologies ensures a minimal carbon footprint, making it an ideal choice for environmentally conscious individuals and businesses.product-1375-718



FAQ



How durable is the Expandable Container House?


Our expandable container house is built to last. The structure is reinforced with high-strength steel and designed to withstand extreme weather conditions. The containers themselves have been tested for durability in international shipping, ensuring your new home or office is both robust and reliable.

Is it easy to expand the house?


Absolutely. The expansion process is straightforward and can be completed in a relatively short timeframe. Our team provides comprehensive instructions and, if needed, can arrange for professional installation services. The modular design allows for seamless integration of additional units, ensuring a hassle-free expansion experience.

What about insulation and temperature control?


Insulation is a top priority in our expandable container house design. We use advanced insulation materials to maintain a consistent indoor temperature, reducing energy consumption and ensuring year-round comfort. Additionally, our energy-efficient windows and doors further enhance thermal performance, creating a cozy and efficient living space.

Are there limitations on customization?product-1080-1440


Customization options are virtually limitless. From interior layouts to exterior finishes, you can tailor the expandable container house to reflect your personal style and functional requirements. Our design team works closely with you to bring your vision to life, ensuring a truly unique and personalized living experience.

How does it impact the environment?


Our expandable container house is a sustainable choice that minimizes environmental impact. By repurposing shipping containers, we reduce waste and conserve natural resources. Additionally, the use of eco-friendly materials and energy-saving technologies contributes to a lower carbon footprint, making it an ideal solution for those committed to green living.
Conclusion
